    CF-500 Snapfurl


    Snapfurl CF-500 represents the latest in quality Schaefer design and engineering. The CF-500 features a unique interlocking Round Geon (tm) PVC foil that allows for owner installation over your existing headstay with no modfications. The foils also lend themselves to trailering boats to ease the problems with mast raising or lowering.

    The CF-500 features a reinforced injection molded Torque Tube and Upper Swivel for incredible strength and lightness. The lower drum and upper swivel feature a double race of Torlon(tm) ball bearings for easy reefing or furling.

    Overall Length: 31'-1'" (9.5m)
    Extrusion: One length single groove uses #5 luff tape
    Bearings: 3/8" (9.5mm) Torlon (tm) ball bearings. (31) in upper swivel (40) in lower drum
    Drum: 2" diameter
    Line Capacity: 25' (7.6m) 1/4" (6mm) line. 19' (5.8m) 5/16" (8mm) line.
    Overall Weight: 15.7 lbs

    Shipping weight is 90 lbs due to oversized packaging. Free UPS Ground shipping in the continental US.

    Contact Schaefer for a local dealer near you for your best price!

    Schaefer Marine, Inc. warrants its standard catalog products to be free from factory defects in material and workmanship for a period of ten (10) years from the date of purchase, unless otherwise stated in this catalog or any other Schaefer Marine catalog. * Furling, Tuff Luff, and Windlass products have shorter warranties and are shown per product.

    We offer free shipping on orders over $100. All other orders are shipped via UPS. For orders outside of the U.S., contact our sales team for custom quote:

    Fitting products to your boat is not one size fits all, feel free to reach out to our team for assistance at 508-995-9511 or
