7 Series Halyard Lift Turning Block / Delrin 704-60
704-60
$136.45
704-60 Halyard/Control block. Delrin(tm) sheave ensures smooth operation and high strength. Anodized aluminum cheeks and Stainless steel base provide solid platform. Block is mounted to bisect load angle for maximum tensile strength. Sheave Dia. 2-3/8, (60 mm), Max Wire 5/8 (16 mm), Jaw Opening 2-9/16, (65 mm), Pin. Dia. 2-11/32, (59 mm), Length 3-3/16, (81 mm), Width 15/16, (24 mm), T (4), 1/4, RH (6 mm), C/C Length 1-15/16, (49 mm), C/C Across 1-3/4, (44 mm), SWL 2250 lbs. (1020 kg). 8.1 oz.
Schaefer Marine, Inc. warrants its standard catalog products to be free from factory defects in material and workmanship for a period of ten (10) years from the date of purchase, unless otherwise stated in this catalog or any other Schaefer Marine catalog. * Furling, Tuff Luff, and Windlass products have shorter warranties and are shown per product.
We offer free shipping on orders over $100. All other orders are shipped via UPS. For orders outside of the U.S., contact our sales team for custom quote: sales@schaefermarine.com
Fitting products to your boat is not one size fits all, feel free to reach out to our team for assistance at 508-995-9511 or sales@schaefermarine.com
